Welded Wire Mesh
WELDED WIRE MESH
Welded wire mesh products are offered as peer BS Standards in Mild Steel Black Finish, Hot Dip Galvanized Steel & other special alloys. Weld Mesh is one of the most versatile of all wire cloth products. Weld mesh is welded steel wire mesh manufactured from bright drawn mild steel wire, electrically welded at all intersections. It is produced with a copper washed finish and can be hot dip galvanized after manufacture. Because it is welded, it can be cut or bent to the shapes required without the wires falling apart and forms its own selvage when cut flush. Weld mesh is available in panels in a variety of wire diameters and meshes up to 8”. The physical properties of the wires are rigidly are controlled to produce a welded mesh which has maximum weld strength. We offer wide range of weld mesh in panel as well as roll form and the standard products available are follows.
| Aperture Size | Wire Dia | Available Type | Material |
|---|---|---|---|
| 200MM X 200MM | 4MM to 8MM | In Panels | MS, GI & Stainless Steel |
| 150MM X 150MM | 3MM to 8MM | In Panels | MS, GI & Stainless Steel |
| 100MM X 100MM | 3MM to 8MM | In Panels/Rolls | MS, GI & Stainless Steel |
| 75MM X 100MM | 3MM to 8MM | In Panels/Rolls | MS, GI & Stainless Steel |
| 100MM X 75MM | 3MM to 8MM | In Panels/Rolls | MS, GI & Stainless Steel |
| 50MM X 50MM | 3MM to 6MM | In Panels/Rolls | MS, GI & Stainless Steel |
WIDTH: Range from 910MM, 1000MM, 1200MM, 1500MM & 2000MM.
LENGTH: In panels & rolls as per the requirement of the customer.
